Protein detail
KCNH8
Voltage-gated delayed rectifier potassium channel KCNH8 (ELK1) (hElk-1) (Ether-a-go-go-like potassium channel 3) (ELK channel 3) (ELK3) (Potassium voltage-gated channel subfamily H member 8) (Voltage-gated potassium channel subunit Kv12.1)
Entry name KCNH8 | UniProt ID | EVMP confidence score 0.53 |
Supporting publications (n) 2 | Transmembrane count 6 | Protein classification Predicted membrane proteinsVoltage-gated ion channels |
Annotation confidence score; open for threshold definitions.
Extremely high >= 0.70High >= 0.60Medium >= 0.40Low >= 0.30Basic Information
Protein Names
Voltage-gated delayed rectifier potassium channel KCNH8 (ELK1) (hElk-1) (Ether-a-go-go-like potassium channel 3) (ELK channel 3) (ELK3) (Potassium voltage-gated channel subfamily H member 8) (Voltage-gated potassium channel subunit Kv12.1)
Protein Class (2)
Predicted membrane proteinsVoltage-gated ion channels
Protein Function
Voltage-gated ion channels:Voltage-Gated Potassium Channels
Transmembrane
226..246; Helical; Name=Segment S1; 256..276; Helical; Name=Segment S2; 299..319; Helical; Name=Segment S3; 328..348; Helical; Voltage-sensor; Name=Segment S4; 358..378; Helical; Name=Segment S5; 449..469; Helical; Name=Segment S6
Transmembrane Count
6
Ensembl
Entrez Gene Symbol
Gene Synonym (2)
elk3Kv12.1
Gene Description
Potassium voltage-gated channel subfamily H member 8
Chromosome
3
Position
19148510-19535642
Supporting publications (n)
2
EVMP confidence score
0.53
Fluorescence & Localization
Function & Pathway
Protein Function
Voltage-gated ion channels:Voltage-Gated Potassium Channels
Cellular Component (2)
Molecular Function (2)
Biological Process (3)
Reactome (3)
Mediation Categories (2)
Clinical-translation mediationFusion and delivery mediation
Relations & Evidence18
Ligand-Receptor Signaling (17)
17 records.
| Category | Parent | Database | Transmitter | Receiver | Secreted | Plasma Membrane (Transmembrane) | Plasma Membrane (Peripheral) |
|---|---|---|---|---|---|---|---|
| ion_channel | ion_channel | DGIdb | Yes | ||||
| voltage_gated_potassium | ion_channel | HGNC | Yes | ||||
| ion_channel | ion_channel | HGNC | Yes | ||||
| ion_channel | ion_channel | Almen2009 | Yes | ||||
| potassium | ion_channel | Almen2009 | Yes | ||||
| voltage_gated | ion_channel | Almen2009 | Yes | ||||
| transporter | transporter | OmniPath | Yes | ||||
| ion_channel | ion_channel | OmniPath | Yes | ||||
| transmembrane | transmembrane | UniProt_location | |||||
| transmembrane | transmembrane | UniProt_topology |
Page 1 of 2Next
Sequence, Structure & Domains
Sequences
Length
1,107
Mass
123,804
Sequence
MPVMKGLLAPQNTFLDTIATRFDGTHSNFILANAQVAKGFPIVYCSDGFCELAGFARTEVMQKSCSCKFLFGVETNEQLMLQIEKSLEEKTEFKGEIMFYKKNGSPFWCLLDIVPIKNEKGDVVLFLASFKDITDTKVKITPEDKKEDKVKGRSRAGTHFDSARRRSRAVLYHISGHLQRREKNKLKINNNVFVDKPAFPEYKVSDAKKSKFILLHFSTFKAGWDWLILLATFYVAVTVPYNVCFIGNDDLSTTRSTTVSDIAVEILFIIDIILNFRTTYVSKSGQVIFEARSICIHYVTTWFIIDLIAALPFDLLYAFNVTVVSLVHLLKTVRLLRLLRLLQKLDRYSQHSTIVLTLLMSMFALLAHWMACIWYVIGKMEREDNSLLKWEVGWLHELGKRLESPYYGNNTLGGPSIRSAYIAALYFTLSSLTSVGFGNVSANTDAEKIFSICTMLIGALMHALVFGNVTAIIQRMYSRWSLYHTRTKDLKDFIRVHHLPQQLKQRMLEYFQTTWSVNNGIDSNELLKDFPDELRSDITMHLNKEILQLSLFECASRGCLRSLSLHIKTSFCAPGEYLLRQGDALQAIYFVCSGSMEVLKDSMVLAILGKGDLIGANLSIKDQVIKTNADVKALTYCDLQCIILKGLFEVLDLYPEYAHKFVEDIQHDLTYNLREGHESDVISRLSNKSMVSQSEPKGNGNINKRLPSIVEDEEEEEEGEEEEAVSLSPICTRGSSSRNKKVGSNKAYLGLSLKQLASGTVPFHSPIRVSRSNSPKTKQEIDPPNHNKRKEKNLKLQLSTLNNAGPPDLSPRIVDGIEDGNSSEESQTFDFGSERIRSEPRISPPLGDPEIGAAVLFIKAEETKQQINKLNSEVTTLTQEVSQLGKDMRNVIQLLENVLSPQQPSRFCSLHSTSVCPSRESLQTRTSWSAHQPCLHLQTGGAAYTQAQLCSSNITSDIWSVDPSSVGSSPQRTGAHEQNPADSELYHSPSLDYSPSHYQVVQEGHLQFLRCISPHSDSTLTPLQSISATLSSSVCSSSETSLHLVLPSRSEEGSFSQGTVSSFSLENLPGSWNQEGMASASTKPLENLPLEVVTSTAEVKDNKAINV
Alternative Products
Event=Alternative splicing; Named isoforms=2; Name=1; IsoId=Q96L42-1; Sequence=Displayed; Name=2; IsoId=Q96L42-2; Sequence=VSP_057036, VSP_057037, VSP_057038, VSP_057039
Alternative Sequence
1..359; Missing (in isoform 2); 459; A -> VSQFQVCPRPSWIICWFRNHFGFILLMTT (in isoform 2); 515..516; WS -> CF (in isoform 2); 517..1107; Missing (in isoform 2)
Domain & Motif Annotations
Compositional Bias
686..702; Polar residues; 710..724; Acidic residues; 961..972; Polar residues
Motif
434..439; Selectivity filter
Domain (FT)
18..90; PAS; 93..145; PAC
Region
551..668; cNMP-binding domain; 686..742; Disordered; 764..791; Disordered; 818..847; Disordered; 961..989; Disordered
Protein Families (3)
- Potassium channel family
- H (Eag) (TC 1.A.1.20) subfamily
- Kv12.1/KCNH8 sub-subfamily
Sequence Similarities
Belongs to the potassium channel family. H (Eag) (TC 1.A.1.20) subfamily. Kv12.1/KCNH8 sub-subfamily.
Clinical Relevance
Drug Targets
Literature-reported target
Drugs (6)
Supporting Publications2
| PMID | Title | Related sentences |
|---|---|---|
| 38113368 | In-Depth Proteome Profiling of Small Extracellular Vesicles Isolated from Cancer Cell Lines and Patient Serum. | No related sentences available |
| 41068253 | Identification of plasma extracellular vesicle protein biomarkers in diabetic retinopathy progression. | No related sentences available |
